The UCP205-16 stainless steel two-bolt pillow block bearing features a 1" bore and is designed to support rotating shafts in food processing, washdown systems, marine equipment, outdoor machinery, and other applications where corrosion resistance is important.
Its stainless steel housing features a solid base construction that provides a rigid mounting platform for stable support while offering improved resistance to moisture, frequent cleaning, and corrosive environments. The self-aligning bearing insert accommodates minor shaft misalignment, while dual set screws securely lock the bearing to the shaft. An integrated grease fitting allows for convenient relubrication and routine maintenance.
Key dimensions include a 4.13-inch bolt-hole center distance, 5.51-inch overall base length, and 2.80-inch height to help verify mounting and replacement compatibility.
SSUCP205-16 Dimensions
Bore Size: 1 in
Style: 2 Bolts
Material: Stainless Steel
Dynamic Load Rating: 14 kN/3100 lbs
Max RPM: 3400
Static Load Rating: 7.85 kN/1800 lbs
Center Bolt Hole to Center Bolt Hole (e): 4.13 in
Overall Height (w): 2.80 in
Overall Length (a): 5.51 in
Bolt Used: 3/8 in
Housing Number: P205
