Aluminium Right Angle Gear Units

The Jeremywell aluminum right angle gearbox is a compact powerhouse engineered for seamless power transmission in tight spaces. Ideal for applications requiring precise torque delivery at a right angle, this gearbox is a versatile solution for various industries. Whether you're automating machinery, enhancing conveyor systems, or optimizing agricultural equipment, our gearbox ensures smooth operation and reliable performance. Crafted from lightweight yet durable aluminum, it's built to withstand the rigors of industrial use while maintaining efficiency.

Common Applications:

- Manual Fertilizer Distributor / Salt Spreader
- Double Disc Fertilizer Spreader
- Sawmills
- Mini Rotary Tiller
- Small Rotary Cultivator

Gears High-Grade Materials:

- 16 NiCr4, according to standard UNI 5331 – AISI 3115
- 20 Mn Cr5

Castings High-Grade Materials:

- Aluminum specifications GD – Lsi 12 cu according to standard UNI 5076
- Black cast iron G25 according to standard UNI ISO 185
- Ductile iron GS 400 according to standard UNI ISO 1083

Shafts High-Grade Materials

- C 43 according to standard UNI EN 1083/1 AISI 1040
- 20Mn Cr5

Power

For optimal product utilization, we advise carefully reviewing the specifications outlined in our technical sheet. Additionally, take into account factors such as input rotation speed, power input, and transmission ratios.

Lubrication

The reducer is typically supplied without lubricant. The recommended quantity of lubricant differs according to model. The first replacement must be done after 50-60 hours of running, then replaced after 600-800 working hours. You must empty the gearbox immediately after use, while the oil is still hot, to avoid the deposition of sludge. Clean the oil plugs. Check the oil level frequently and top off the oil whenever necessary.
